PLP Pneumatic Link Clamp - Leverage Clamp
Product features :
- ideal for use in a wide field of applications : Jigs, fixtures, plastic injection moulding, testing, CNC machining, welding…
- compact series with lever for use in tight spaces
- Material: Aluminium alloy body
- Clamping arm is C45 Carbon Steel
- lightweight, robust and reliable
- high durability
- Holding capacity 0,2kN up to 4,69kN
- Magnetic piston optional (for end position monitoring with optional sensors)
- complete with clamping arm
- double acting
- Operating pressure : 3 to 7 bar
- Range of Temperature : -10 〜 +60C°
Note :
- Operate only with filtered and lubricated air.
- Customized modifications are possible !
➝ CAD-files are available to download (see below) !
Product Datasheet (Download)| ① | SERIES | PLP | |
| ② | Piston type | Blank : Standard type (non-magnetic) MS : with magnetic induction (for position monitoring) |
|
| ③ | Cylinder inside diameter | ø25, ø32, ø40, ø50, ø63, ø80, ø100 | |
| ④ | Sensor switch (reed sensor) | S1 : 1 Sensor S2 : 2 Sensors |
| Model No. | Clamping Force at 7 bar [kN] | Clamping Stroke [mm] | TOTAL STROKE [mm] | Cylinder Capacity Clamp | Unclamp [cm3] | Weight Standard/MS [kg] | CAD Download Standard | MS | Prices from EUR/pcs. Standard | MS |
|---|---|---|---|---|---|---|---|
| PLP-25 | 0,20 | 17 | 20 | 9,82 | 8,24 | 0.24 | 0.29 | | | 119,00 | 139,00 |
| PLP-32 | 0,31 | 20 | 23 | 18,49 | 15,89 | 0.42 | 0.48 | | | 129,00 | 139,00 |
| PLP-40 | 0,56 | 22 | 25 | 31,40 | 26,40 | 0.55 | 0.63 | | | 139,00 | 159,00 |
| PLP-50 | 0,91 | 27 | 30 | 58,89 | 49,47 | 0.95 | 1.05 | | | 159,00 | 189,00 |
| PLP-63 | 1,69 | 32 | 35 | 109,06 | 98,00 | 1.45 | 1.60 | | | 189,00 | 219,00 |
| PLP-80 | 2,79 | 40 | 43 | 216,03 | 195,22 | | | 269,00 | 289,00 | |
| PLP-100 | 4,69 | 45 | 48 | 376,80 | 338,40 | - | | | 359,00 | 389,00 |
| MODEL | Standard Type | With Magnet | C1 | C2 | ΦD | E | F | G1 | G2 | G3 | H | J | J1 | K | L | L1 | M | N | α | Q | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A1 | B | A1 | B | |||||||||||||||||||
| PLP-25 | 65,5 | 41 | 75,5 | 51 | 13 | 6 | Φ5 | 25 | 50 | 45 | 14 | 17 | 3 | 40 | - | 28 | M5x0.8 | 10,5 | M5x0.8 | 8 | 75° | ø10 |
| PLP-32 | 78 | 49 | 93 | 64 | 16 | 8 | Φ6 | 31 | 60 | 53 | 17 | 20 | 3 | 44 | 50 | 34 | M5x0.8 | 11 | PT1/8 | 9 | 70° | ø12 |
| PLP-40 | 82,5 | 51,5 | 97,5 | 66,5 | 16 | 8 | Φ6 | 32 | 65 | 58 | 20 | 22 | 3 | 52 | 58 | 40 | M6x1.0 | 9,5 | PT1/8 | 10 | 65° | ø16 |
| PLP-50 | 96,6 | 58,6 | 106,6 | 68,6 | 19 | 10 | Φ8 | 35 | 75 | 66 | 23 | 27 | 3 | 62 | 71 | 48 | M6x1.0 | 11 | PT1/4 | 11 | 70° | ø20 |
| PLP-63 | 115,5 | 72,5 | 125,5 | 82,5 | 22 | 10 | Φ8 | 38,5 | 85 | 76 | 29,5 | 32 | 3 | 75 | 84,5 | 60 | M6x1.0 | 11 | PT1/4 | 11 | 65° | ø20 |
| PLP-80 | 138 | 84 | 148 | 94 | 22 | 10 | Φ10 | 47 | 105 | 94 | 37 | 40 | 3 | 94 | 104 | 74 | M8 | 15,5 | PT1/4 | 14 | 65° | ø25 |
| PLP-100 | 163,5 | 99 | 173,5 | 109 | 25 | 12 | Φ12 | 53 | 125 | 110 | 45 | 45 | 3 | 114 | 124 | 90 | M10 | 15 | PT1/4 | 18 | 60° | ø32 |
Sensors for PLP-SERIES DFSJ, DFSJN, DFSJP
