DST-36330-A Pneumatic push-pull toggle clamp 11360N

DST-36330-A Pneumatic push-pull toggle clamp with cast iron body 11360N

Standard, Light Duty Pneumatic Clamp :

  • Straight Line Action Clamp
  • heavy version with cast iron body for long operating life
  • double acting pneumatic cylinder, ready to connect
  • Pneumatic version of manual toggle clamp DST-36330-M
  • Lever parts and rod : galvanic, zinc-plated high quality steel
  • optional magnetic piston for end position monitoring/sensoring
  • optional Proximity sensors available
  • CAD files on request !
Product Datasheet (Download)
Modell-Nr.DST-36330-A
Holding Capacity 11360 N
Weight 2570 g
Cylinder Bore 40 mm
Plunger Stroke 28 mm
Cylinder Area 12,56 cm2
max. cylinder air pressure 10 bar
Port Size G 1/8
Price on request

DST-36330-A Drawing/Dimension DST-36330-A Pneumatic push-pull toggle clamp 11360N
